IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH144
User Manual uEye Cameras V3.32
UI-222x / UI-622x
Sensor specification
Sensor type
CCD
Shutter system
Electronic global shutter
Readout mode
Progressive scan
Resolution class
CCIR/PAL
Resolution
768 x 576 pixels (0.44 Mpixels)
Aspect ratio
4:3
Bit depth
12 bits
Optical sensor class
1/2 inch
Exact sensitive area
6.37 x 4.78 mm
Exact optical sensor diagonal
8.0 mm (1/2.0 inch)
Pixel size
8.3 µm, square
Sensor name, monochrome
Sony ICX415AL
Sensor name, color
Sony ICX415AQ
Gain
Monochrome model (master gain)
14.1x
Color model (master/RGB)
8.9x/4.0x
Offset control, mode
Auto/manual, additive
Gain boost
2.0x (monochrome model only)
Camera timing
USB uEye
GigE uEye SE
GigE uEye HE
Pixel clock range
MHz
5-30
*1)
5-30
*1)
5-30
*1)
Pixel clock range (with subsampling/binning)
MHz
5-30
*1)
5-30
*1)
5-30
*1)
Frame rate (freerun mode)
fps
52
*2)
52
*2)
52
*2)
Frame rate (trigger mode, 1 ms exposure)
fps
47
*2)
47
*2)
47
*2)
Exposure time in freerun mode
ms
0.05 *
2)
-770
*3)
0.05 *
2)
-770
*3)
0.05 *
2)
-770
*3)
Exposure time in trigger mode
ms
0.05 *
2)
-10 min
*3)
0.05 *
2)
-10 min
*3)
0.05 *
2)
-10 min
*3)
AOI
Mode
Horizontal + Vertical
*4)
AOI image width, step width
Pixels
16 - 768, 4
16 - 768, 4
16 - 768, 4
Mono: AOI image height, step width
Pixels
120 - 576, 1
120 - 576, 1
120 - 576, 1
Color: AOI image height, step width
Pixels
120 - 576, 2
120 - 576, 2
120 - 576, 2
Mono: AOI position grid horizontal, vertical
Pixels
1, 1
1, 1
1, 1
Color: AOI position grid horizontal, vertical
Pixels
2, 2
2, 2
2, 2
AOI frame rate, 640 x 480 pixels (VGA)
fps
60
60
60
AOI frame rate, 320 x 240 pixels (CIF)
fps
97
97
97
Binning
Mode
Vertical
*4)
Horizontal +
Vertical
*4)
Horizontal +
Vertical
*4)
