9 Specifications
Method
V: Monochrome
binning, additive
H + V:
Monochrome
binning, additive
H + V:
Monochrome
binning, additive
Frame rate with 2x binning, 768 x 288 pixels
fps
90
90
90
Frame rate with 3x binning, 768 x 192 pixels
fps
121
121
121
Frame rate with 4x binning, 768 x 144 pixels
fps
143
143
143
Subsampling
Mode
-
-
-
Hardware trigger
Mode
Asynchronous
Asynchronous
Asynchronous
Trigger delay with rising edge
µs
43.2 ±4
< 5
< 5
Trigger delay with falling edge
µs
61.5 ±4
< 5
< 5
Additive trigger delay (optional)
µs
15 µs-4 s
15 µs-4 s
15 µs-4 s
Sensor delay to exposure start
µs
< 100
*2)
< 100
*2)
< 100
*2)
Connected load
*5)
USB uEye
GigE uEye SE
GigE uEye HE
W
1.0-1.9
3.0-4.0
3.5-5.4
*1)
The maximum possible pixel clock frequency depends on the PC hardw are used.
*2)
Requires maximum pixel clock frequency.
*3)
Requires minimum pixel clock frequency.
*4)
Use of the function increases the frame rate for monochrome models.
*5)
The connected load depends on the sensor model and the pixel clock setting.
Relative sensor sensitivity
Monochrome
Color
Figure 102: Sensor sensitivity of the UI-222x / UI-622x

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
