Sensor specification
Sensor type
CCD
Shutter system
Electronic global shutter
Readout mode
Progressive scan
Resolution class
SXGA
Resolution
1280 x 1024 pixels (1.3 Mpixels)
Aspect ratio
4:3
Bit depth
12 bits
Optical sensor class
1/2 inch
Exact sensitive area
5.95 x 4.76 mm
Exact optical sensor diagonal
7.6 mm (1/2.1 inch)
Pixel size
4.65 µm, square
Sensor name, monochrome
Sony ICX205AL
Sensor name, color
Sony ICX205AK
Gain
Monochrome model (master gain)
13.66x
Color model (master/RGB)
4.0x/8.9x
Offset control, mode
Auto/manual, additive
Gain boost
2.0x (monochrome model only)
Camera timing
USB uEye
GigE uEye SE
GigE uEye HE
Pixel clock range
MHz
5-30
*1)
5-30
*1)
5-30
*1)
Pixel clock range (with subsampling/binning)
MHz
5-30
*1)
5-30
*1)
5-30
*1)
Frame rate (freerun mode)
fps
15
*2)
15
*2)
15
*2)
Frame rate (trigger mode, 1 ms exposure)
fps
15
*2)
15
*2)
15
*2)
Exposure time in freerun mode
ms
0.083 *
2)
-1460
*3)
0.083 *
2)
-1460
*3)
0.083 *
2)
-1460
*3)
Exposure time in trigger mode
ms
0.083 *
2)
-10 min
*3)
0.083 *
2)
-10 min
*3)
0.083 *
2)
-10 min
*3)
AOI
Mode
Horizontal + Vertical
*4)
AOI image width, step width
Pixels
16 - 1280, 4
16 - 1280, 4
16 - 1280, 4
Mono: AOI image height, step width
Pixels
120 - 1024, 1
120 - 1024, 1
120 - 1024, 1
Color: AOI image height, step width
Pixels
120 - 1024, 2
120 - 1024, 2
120 - 1024, 2
Mono: AOI position grid horizontal, vertical
Pixels
1, 1
1, 1
1, 1
Color: AOI position grid horizontal, vertical
Pixels
2, 2
2, 2
2, 2
AOI frame rate, 1024 x 768 pixels (XGA)
fps
18
18
18
AOI frame rate, 640 x 480 pixels (VGA)
fps
28
28
28
AOI frame rate, 320 x 240 pixels (CIF)
fps
38
38
38
Binning
