9 Specifications
Mode
Vertical
*4)
Horizontal +
Vertical
*4)
Horizontal +
Vertical
*4)
Method
V: Monochrome
binning, additive
H + V:
Monochrome
binning, additive
H + V:
Monochrome
binning, additive
Frame rate with 2x binning, 1280 x 512 pixels
fps
23
23
23
Frame rate with 3x binning, 1280 x 340 pixels
fps
28
28
28
Frame rate with 4x binning, 1280 x 256 pixels
fps
31
31
31
Subsampling
Mode
Vertical
*4)
Vertical
*4)
Horizontal +
Vertical
*4)
Method
V: Color
subsampling
V: Color
subsampling
H + V: Color
subsampling
Frame rate w/ 4x subsampling, 1280 x 256
pixels
fps
31
31
31
Hardware trigger
Mode
Asynchronous
Asynchronous
Asynchronous
Trigger delay with rising edge
µs
43.2 ±4
< 5
< 5
Trigger delay with falling edge
µs
61.5 ±4
< 5
< 5
Additive trigger delay (optional)
µs
15 µs-4 s
15 µs-4 s
15 µs-4 s
Sensor delay to exposure start
µs
< 100
*2)
< 100
*2)
< 100
*2)
Connected load
*5)
USB uEye
GigE uEye SE
GigE uEye HE
W
1.1-2.1
3.1-4.2
3.7-5.6
*1)
The maximum possible pixel clock frequency depends on the PC hardw are used.
*2)
Requires maximum pixel clock frequency.
*3)
Requires minimum pixel clock frequency.
*4)
Use of the function increases the frame rate for monochrome models.
*5)
The connected load depends on the sensor model and the pixel clock setting.

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
