IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH152
User Manual uEye Cameras V3.32
Relative sensor sensitivity
Monochrome
Color
Figure 104: Sensor sensitivity of the UI-224x / UI-624x
Notes on using the UI-224x / UI-624x
· Optimum pixel clock frequency is 14 MHz.
· Recommended pixel clock range 10 - 20 MHz.
· Long exposure times will increase the number of hotpixels.
· High temperatures will increase the black level of individual pixels.
· When vertical 4x binning is activated, the minimum image width increases to 640
pixels.

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
