9 Specifications
UI-225x / UI-625x
Sensor specification
Sensor type
CCD
Shutter system
Electronic global shutter
Readout mode
Progressive scan
Resolution class
UXGA
Resolution
1600 x 1200 pixels (1.92 Mpixels)
Aspect ratio
4:3
Bit depth
12 bits
Optical sensor class
1/1.8 inch
Exact sensitive area
7.04 x 5.28 mm
Exact optical sensor diagonal
8.8 mm (1/1.8 inch)
Pixel size
4.4 µm, square
Sensor name, monochrome
Sony ICX274AL
Sensor name, color
Sony ICX274AK
Gain
Monochrome model (master gain)
13.78x
Color model (master/RGB)
8.9x/4.0x
Offset control, mode
Auto/manual, additive
Gain boost
2.0x (monochrome model only)
Camera timing
USB uEye
GigE uEye SE
GigE uEye HE
Pixel clock range
MHz
5-30
*1)
5-30
*1)
5-30
*1)
Pixel clock range (with subsampling/binning)
MHz
5-30
*1)
5-30
*1)
5-30
*1)
Frame rate (freerun mode)
fps
12.5
*2)
12.5
*2)
12.5
*2)
Frame rate (trigger mode, 1 ms exposure)
fps
12
*2)
12
*2)
12
*2)
Exposure time in freerun mode
ms
0.094 *
2)
-1570
*3)
0.094 *
2)
-1570
*3)
0.094 *
2)
-1570
*3)
Exposure time in trigger mode
ms
0.094 *
2)
-5000
*3)
0.094 *
2)
-5000
*3)
0.094 *
2)
-5000
*3)
AOI
Mode
Horizontal + Vertical
*4)
AOI image width, step width
Pixels
320 - 1600, 4
320 - 1600, 4
320 - 1600, 4
Mono: AOI image height, step width
Pixels
240 - 1200, 1
240 - 1200, 1
240 - 1200, 1
Color: AOI image height, step width
Pixels
240 - 1200, 2
240 - 1200, 2
240 - 1200, 2
Mono: AOI position grid horizontal, vertical
Pixels
1, 1
1, 1
1, 1
Color: AOI position grid horizontal, vertical
Pixels
2, 2
2, 2
2, 2
AOI frame rate, 1024 x 768 pixels (XGA)
fps
18
18
18
AOI frame rate, 640 x 480 pixels (VGA)
fps
28
28
28
AOI frame rate, 320 x 240 pixels (CIF)
fps
47
47
47
Binning
