IDS uEye series User Manual

© 2009 IDS Imaging Development Systems GmbH154
User Manual uEye Cameras V3.32
Mode
Vertical
*4)
Horizontal +
Vertical
*4)
Horizontal +
Vertical
*4)
Method
V: Monochrome
binning, additive
H + V:
Monochrome
binning, additive
H + V:
Monochrome
binning, additive
Frame rate with 2x binning, 1600 x 600 pixels
fps
24
24
24
Frame rate with 3x binning, 1600 x 400 pixels
fps
34
34
34
Frame rate with 4x binning, 1600 x 300 pixels
fps
43
43
43
Subsampling
Mode
Vertical
*4)
Vertical
*4)
Horizontal +
Vertical
*4)
Method
V: Color
subsampling
V: Color
subsampling
H + V: Color
subsampling
Frame rate w/ 2x subsampling, 1600 x 600
pixels
fps
24
24
24
Frame rate w/ 4x subsampling, 1600 x 300
pixels
fps
43
43
43
Hardware trigger
Mode
Asynchronous
Asynchronous
Asynchronous
Trigger delay with rising edge
µs
43.2 ±4
< 5
< 5
Trigger delay with falling edge
µs
61.5 ±4
< 5
< 5
Additive trigger delay (optional)
µs
15 µs-4 s
15 µs-4 s
15 µs-4 s
Sensor delay to exposure start
µs
< 100
*2)
< 100
*2)
< 100
*2)
Connected load
*5)
USB uEye
GigE uEye SE
GigE uEye HE
W
1.0-2.4
3.0-4.4
3.8-6.2
*1)
The maximum possible pixel clock frequency depends on the PC hardw are used.
*2)
Requires maximum pixel clock frequency.
*3)
Requires minimum pixel clock frequency.
*4)
Use of the function increases the frame rate for monochrome models.
*5)
The connected load depends on the sensor model and the pixel clock setting.

IDS uEye series Specifications

General

Sensor	CMOS
Interface	USB 2.0, USB 3.0, GigE
Shutter	Global or Rolling Shutter
Power Supply	Via USB or external power (depending on model)
Operating System	Windows, Linux
Mount	C-mount or CS-mount
Dimensions	29 x 29 x 29 mm
