© 2009 IDS Imaging Development Systems GmbH 163
9 Specifications
9.2.2 Dimensions
Figure 131: USB uEye RE
Enclosure protection class
145 g (CMOS), 180 g (CCD)
For the dimensions of the USB uEye RE accessories, please refer to the USB uEye RE
Accessories chapter.
Differences to the USB uEye SE
The USB uEye RE features the following modifications compared to the standard USB uEye SE
models:
· Binders series 712 is used for the connector. This series is approved for the IP 65 and IP 67
standards.
· The housing parts are sealed against each other with O-rings:
§ Rear panel/centerpiece
§ Centerpiece/front panel
§ Front panel/tube
· The LED light conductor is bonded.
· Tubes in different lengths are optionally available for sealing the lens.
· M3 and M5 mounting options are provided on the housing.
The USB uEye RE housing variant is IP 65/67 compliant. The following requirements must
be met for compliance with the IP 65/67 standards:
· Cables must be attached to both connectors (USB and trigger) during operation. If the
trigger connector is not used, it must be closed with the cover.
· A tube must be connected.
Attention: The USB uEye RE has not been approved for underwater use.
