© 2009 IDS Imaging Development Systems GmbH90
User Manual uEye Cameras V3.32
Size
On this tab, you can set the image size parameters for your uEye camera (see also Reading out
Partial Images).
Figure 77: uEye properties - Size
· AOI
These parameters allow selecting the size and position of the area of interest.
· Show only AOI
The AOI is displayed without a black border. Internally, the image is managed at the AOI
resolution and not the full sensor resolution. This function saves memory and computing time
when rendering the image.
§ Width
Sets the AOI width.
§ Height
Sets the AOI height.
§ Left
Sets the left-hand position of the AOI.
§ Center
Select this check box to center the AOI horizontally.
§ Top
Sets the top position of the AOI.
§ Center
Select this check box to center the AOI vertically.
· Horizontal format / Vertical format
With these check boxes and radio buttons, you can select the binning and subsampling settings
for the image.
