ROCKY-4786EV/EVG User Manual
Page 7
SPECIFICATION
Power Management Supports Advanced Configuration and Power Interface
(ACPI) Specifications Revision 2.0
Infrared Support One Infrared Data Association (IrDA) interface
Ethernet RJ-45 10/100BaseT
RJ-45Gigabit Ethernet (GbE) with ASF 2.0 remote
control support (ROCKY-4768EVG only)
BIOS Award BIOS
Audio Interfaces One Audio Codec ’97 (AC’97) version 2.2 connector
Physical Dimensions 338 mm x 122 mm (length x width)
Weight 1.1 kg
Power Supply AT/ATX supported
Power Consumption 5V @ 6.98A, 12V @ 7.52A (Intel® Pentium® 4 CPU
3.00GHz 800 MHz FSB with 2GB DDR 400MHz)
Operating Temperature Minimum: 0ºC (32°F)
Maximum: 60°C (140°F)
Humidity (operating) 5% ~ 95% (non-condensing)
Table-1-1: Technical Specifications
