ROCKY-4786EV/EVG User Manual
Page 48
4.3 ROCKY-4786EV/EVG CPU Card Installation
WARNING!
1. Never run the CPU board without an appropriate heat sink and cooler that
can be ordered from IEI Technology or purchased separately.
2. Be sure to use the CPU 12V power connector (CN10007) for the CPU
power.
WARNING!
Please note that the installation instructions described in this manual should
be carefully followed in order to avoid damage to the CPU Card components
and injury to you.
WARNING!
When installing electronic components onto the CPU Card always take the
following anti-static precautions in order to prevent ESD damage to your
board and other electronic components like the CPU and DIMM modules
The following components must be installed onto the CPU Card or connected to the CPU
Card during the installation process.
CPU
CPU cooling kit
DIMM modules
Peripheral device connection
