ROCKY-4786EV/EVG User Manual
Page 25
3.2.5 Internal USB Connectors
CN Label: USB1, USB2, USB3, USB4
CN Type: 2x4 pin header
CN Location: See
Figure-3-6
CN Pinouts: See
Table-3-7
Four 2x4 pin connectors provide connectivity to eight USB 2.0 ports. The USB ports are
used for I/O bus expansion.
PIN DESCRIPTION PIN DESCRIPTION
1 VCC 2 GND
3 DATA0- 4 DATA1+
5 DATA0+ 6 DATA1-
7 GND 8 VCC
Table-3-7: USB Port Connector Pinouts
