ROCKY-4786EV/EVG User Manual
Page 53
4.4 Jumper Settings
NOTE:
A jumper is a metal bridge used to close
an electrical circuit. It consists of two or
three metal pins and a small metal clip
(often protected by a plastic cover) that
slides over the pins to connect them. To
CLOSE/SHORT a jumper means
connecting the pins of the jumper with
the plastic clip and to OPEN a jumper means removing the plastic clip
from a jumper.
The ROCKY-4786EV/EVG includes one jumper shown in table and figure below.
Description Label Type
CF Setup JP1 2-pin header
Clear CMOS jumper JP2 3-pin header
Table 4-1: Jumpers
