ROCKY-4786EV/EVG User Manual
Page 16
CN3 LAN State LED connectors 4-pin header
CN4 LAN State LED connectors 4-pin header
CD-IN Audio CD in connector 4-pin header
LINE-IN Audio LINE in connector 4-pin header
MIC-IN Audio MIC in connector 4-pin header
PW-SW1 ATX Power Button connector 2-pin header
ATXCTL1 Backplane to Main board ATX power
control Connector
3-pin header
Table 3-1: Peripheral Interface Connectors
3.1.3 Rear Panel Connectors
Table 3-2 lists the rear panel connectors on the ROCKY-4786EV/EVG CPU card. Detailed
descriptions of these connectors can be found in Section
3.3.
Label Connector Type
KB/MS1 Keyboard or Mouse connector PS/2
LAN1 Ethernet connector RJ-45
LAN2 Ethernet connector RJ-45
SPK_OUT AUDIO connector LINE OUT
VGA1 VGA connector 15-pin VGA connector
Table 3-2: Peripheral Interface Connectors
3.2 Internal Peripheral Connectors
Internal peripheral connectors are found on the CPU card and are only accessible when
the CPU board is outside of the chassis. This section has complete descriptions of all the
internal, peripheral connectors on the ROCKY-4786EV/EVG CPU board.
3.2.1 FDD Connector
