Chapter 1 Product Overview 3
Ehave Series Full Digital IGBT CO
2
/MAG/MMA Multifunctional Inverter Welder User Manual
Item
Description
Ehave CM250/350
Ehave CM500/500H
Gas type
CO
2
; MAG
CO
2
; MAG
Wire type
Solid wire, flux-cored wire, and
electrode
Solid wire, flux-cored wire, and
electrode
Output control
Synergic/Manual
Synergic/Manual
Wire diameter
0.8; 1.0; 1.2
1.0; 1.2; 1.6
Welding control
Welding with ending arc
Welding without ending arc
Spot welding
Welding with repeated ending arc
Welding with ending arc
Welding without ending arc
Spot welding
Welding with repeated ending arc
Gas detection
Checks before welding whether a
shielding gas is used.
Checks before welding whether a
shielding gas is used.
Wire inching
Inches wire before welding.
Inches wire before welding.
Current and
voltage setup
In synergic mode, the current ranges
from 30 A to (300) 400 A and the
voltage knob is used to finely tune the
voltage within the range of ±9 V.
In manual mode, the current and
voltage are set independently, with
the current ranging from 30 A - (300)
400 A and the voltage ranging from 12
V - (34) 38 V.
In synergic mode, the current
ranges from 30 A to 500A and the
voltage knob is used to finely tune
the voltage within the range of
±9 V.
In manual mode, the current and
voltage are set independently, with
the current ranging from 30 A – 500
A and the voltage ranging from 12
V - 45 V.
Arc dynamic
The knob on the control panel can be
used to set the value within the range
of -9 to +9, where -9 indicates the
softest arc and +9 indicates the
hardest arc.
The knob on the control panel can
be used to set the value within the
range of -9 to +9, where -9
indicates the softest arc and +9
indicates the hardest arc.
Spot welding time
In spot welding mode, the spot
welding time can be set on the control
panel within the range of 0.1 s -
10.0 s.
In spot welding mode, the spot
welding time can be set on the
control panel within the range of
0.1 s - 10.0 s.
Ending arc voltage
The voltage can be set using the knob
on the control panel within the range
of 12 V - (34) 38 V.
The voltage can be set using the
knob on the control panel within the
range of 12 V – 45 V.
Ending arc current
The current can be set using the knob
on the control panel within the range
of 30 A - (300) 400 A.
The current can be set using the
knob on the control panel within the
range of 30 A – 500 A.
Current setup for
manual welding
The current can be set using the knob
on the control panel within the range
of 30 A - (300) 400 A.
The current can be set using the
knob on the control panel within the
range of 30 A - 500A.
ENTER
,
LOAD
, and
SAVE
buttons
They are used to confirm, save, load,
and lock welding parameters.
They are used to confirm, save,
load, and lock welding parameters.
