76 Appendix V Detailed Component List
Ehave Series Full Digital IGBT CO
2
/MAG/MMA Multifunctional Inverter Welder User Manual
Appendix V Detailed Component List
Table 2 Detailed component list
Component
Ehave CM250/350/350AR
Ehave CM500/500H/500AR
Quantity
Code
Quantity
Code
Output EMC board
1
R11110645
1
R11110091
Display board
1
R11100236
1
R11100057
Line-frequency
transformer T3
1
R23011079
1
R23010893
Fan control board
1
R11110087
1
R11110087
Air circuit breaker
1
R34010054
1
R30040897
Cable terminal cover
1
30040908
1
30040908
Cable terminal block
1
30040907
1
30040907
Input EMC board
1
R11110089
1
R11110089
Line-frequency
transformer T4
1
R23011077
1
R23010894
Wire inching control
board
1
R11100235
1
R11100056
Main power board
1
R11110644
1
R11110085
3-phase rectifier
bridge
1
R26060164
1
R26060164
Negative output
terminal
1
30040912
1
30040912
Fuse
2
R27010154
2
R27010154
7-core aviation jack
1
R30040896
1
R30040896
Positive output
terminal
1
30040911
1
30040911
Diode
3
R26020129
3
R26020100
Output absorption
board
1
R11110090
1
R11110090
Inductor
1
R22011204
1
R23010895
Cable terminal block
1
30040910
1
30040910
Fan
1
R34020011
2
R34020011
Hex key
1
R29120011
1
R29120011
Caster
4, Optional
R29120012
4, Optional
R29120012
Plastic panel
1
R29060228
1
R29060228
ZA chassis without
load
1
R29140023
1
R29140001
