IMS ROBOTICS MICRO S - Gear motor issues

MICRO S light plus Cutter motor
Number:
RH-11.014. A
Scope:
IMS Robotics
Document Management
Date:
08 July 2022
Author:
00145
Checked:
Page:
107 of 113
Problem
Possible causes
Test method
Remedy
Gear motor without function
Gear motor without power
Gear motor jerks when turning
• Electrical supply line interrupted
• Brush ring worn out
• Brush block worn out
• Disc slip ring worn
• Mechanical defect
Disassembly gear motor
➔ "Removing the lifting air bag"
➔ "Removing the radial air bag"
➔ "Removing the front rotary unit"
➔ "Removing the disc grinding ring"
➔ "Mounting the disc grinding ring"
Continuity test of all electrical
connections.
Visual inspection for wear of the brush
ring, the brush block and the disc
grinding ring.
Mechanical check of all moving parts.
Replace all worn parts
➔ "Mounting the disc grinding ring"
➔ "Replacing the brush unit in the rotary
unit"
➔ "Motor unit assembly"
Clean all parts of the engine properly,
degrease them and remove any
corrosion. Check the moving parts for
free running and wear, re-grease and
assemble.
➔ "Motor unit assembly"
• Moisture penetration therefore
o Heavily soiled
o Incipient corrosion
Visual assessment of the condition of
the engine with regard to dirt and
corrosion.
In the event of moisture penetration,
additionally replace the X-ring and the
rod seal in the
front rotary actuator.
➔ "Removing the front rotary unit"
