IMS ROBOTICS MICRO S - Air ingress issues

MICRO S light plus Cutter motor
Number:
RH-11.014. A
Scope:
IMS Robotics
Document Management
Date:
08 July 2022
Author:
00145
Checked:
Page:
108 of 113
Problem
Possible causes
Test method
Remedy
Foreign air in the axial muscle
• Axial hose for milling air leaking or
defective
• PU hose or
quick-release fittings for supply line
Radial bladder leaking
• PU hose or quick connector for
supply line Lifting bladder leaking
Connect the test case to the rear
distributor.
o Pressurise the milling air line.
Axial muscle inflates.
Seal or replace the axial hose.
➔ "Removing the axial movement
mechanism"
➔ "Replacing the DN 8 axial hose"
➔ "Compressing axial hose"
Connect the test case to the rear
distributor.
o Pressurise the PU hose for the
radial bladder. Axial muscle
inflates.
Connect the test case to the rear
distributor.
o Pressurise PU hose for lifting
bladder
Axial muscle inflates.
Seal or replace compressed air
connection.
➔ "Removing the axial movement
mechanism"
➔ "Replacing the DN 8 axial hose"
Seal or replace compressed air
connection.
➔ "Removing the axial movement
mechanism"
➔ "Replacing the DN 8 axial hose"
Foreign air in the radial bubble
• Sliding hose
(for lifting air guide) leaking
Connect the test case to the rear
distributor.
o Pressurise PU hose for lifting
bladder
Radial bladder inflates.
Seal or replace the sliding hose
➔ "Removing the radial air bag"
➔ "Replace sliding hose and milling air
hose in radial bladder"
Foreign air in the lifting bubble
• Milling air hose damaged
• Rotary screw connection of the
milling air hose in the
front distributor leaking
• Sliding hose leaking
Connect the test case to the rear
distributor.
o Pressurise the milling air line
o Pressurise the PU hose for the
radial bladder.
Lifting bubble inflates
Seal or replace the sliding hose or
milling air hose. Replace the swivel
fitting.
➔ "Removing the radial air bag"
➔ "Replace sliding hose and milling air
hose in radial bladder"
