IMS ROBOTICS MICRO S - Lifting linkage issues

MICRO S light plus Cutter motor
Number:
RH-11.014. A
Scope:
IMS Robotics
Document Management
Date:
08 July 2022
Author:
00145
Checked:
Page:
109 of 113
Problem
Possible causes
Test method
Remedy
Lifting linkage worn out
• Lugs or axles worn out
• Plain bearing worn
• Axles worn
• Additional spacer bolts are missing.
Manual check of the stability of the
lifting linkage
Dismantle the lifting linkage and replace
all worn parts.
➔ "Removing the lifting air bag"
➔ "Repair lift linkage"
Lifting linkage without function
• Axles torn off
• Axle guide of adapter brackets torn
off or deformed
• Broken or bent straps
• Lifting linkage heavily corroded
Manual check of the stability of the
lifting linkage
Dismantle the lifting linkage and replace
all worn parts.
➔ "Removing the lifting air bag"
➔ "Repair lift linkage"
