MICRO S automatic Cutter motor
4. To stabilise the spring and the axial hose,
a steel wire of approx. 6mm Ø is inserted
through the cutting air hoses.
5. An M5 threaded rod is screwed into the rear
distributor to create counter-pressure when
removing the axial movement mechanism so
that the pressure is released from the axial
hose, the cable and the compressed air hoses
Caution
The axial movement mechanism can only be
dismantled if the rear radial air bag is also
removed.
Caution
The steel wire must be long enough to
reach into the front radial air bag
