IMS ROBOTICS MICRO S - Page 55

MICRO S automatic Cutter motor
Number:
RH-11.014 A
Scope:
IMS Robotics
Document Management
Date:
08 July 2022
Author:
00145
Checked:
Page:
55 of 113
4. This can be done using either a silk cutter
or a cutter knife.
5. The finished axial hose.
Mounting the axial hose according to instructions
"Change axial hose DN8"
