IMS ROBOTICS MICRO S - Page 95

MICRO S automatic Cutter motor
Number:
RH-11.014 A
Scope:
IMS Robotics
Document Management
Date:
08 July 2022
Author:
00145
Checked:
Page:
95 of 113
2. Set the tester to "continuity test".
3. Check all strands against each other at
the distributor (luster terminal).
4. All housings
• Distributor Rear
• Distributor Front
• Rotation gear
Check for short circuit to earth with each
individual strand.
