Transpector XPR 3+ Operating Manual
CAUTION
The air pressure supplied to the valve must be at least
60 psig.
Figure 1-6 INFICON supplied air valve
1.16.2.2 Port Identification for 2-Way, Normally Closed Use
See Figure 1-7.
IN . . . . . . . . . . . . . . . . . . . . . . . . . . . Pressure supply port
OUT . . . . . . . . . . . . . . . . . . . . . . . . . Delivery port to valve
EXH . . . . . . . . . . . . . . . . . . . . . . . . . Exhaust port, plugged
Figure 1-7 Port identification
EXH
IN
OUT
IN
OUT
EXH
2 WAY NORMALLY CLOSED
PLUGGED
INLET
AIR
