1 - 13
Transpector XPR 3+ Operating Manual
1.16.2.3 Valve Parts List
WARNING
This valve has an operational voltage rating of
24 V(dc) +10% to -15%.
Figure 1-8 Valve parts list
Item Description
1 Solenoid Coil
2 Connector Gasket
3 Connector
4 Connector Elbow
5Nut
6 Washer
7 Compression Ring
8Screw
