Appendix A
Interfaces
Interfaces
Cables
A power line cord is provided with the printer, but no data cables. The
following provides data cable requirements and ordering information.
ASCII Serial/Parallel: The 6500-V printer is connected to personal computers
and controllers via industry standard EIA-232-E and PC-parallel printer
cables. For Dataproducts interfaces, you will need to obtain a Dataproducts
cable. Contact your InfoPrint service representative to order the following:
•
EIA-232-E Cable
•
PC-Parallel Cable
•
Dataproducts Adapter Feature
AS/400: The 6500-V is connected to the AS/400 ASCII Workstation Controller
via the following InfoPrint cables, available through your InfoPrint service
representative:
•
20 ft. RS-232
•
40 ft. RS-232
Type Standard IEEE 1284 Parallel, Centronics Parallel, RS-232/RS-
422 Serial (optional), Dataproducts Parallel.
Optional Coax, Twinax, Dataproducts Long Line, Ethernet 10/
100Base-T
Logic Levels TTL/EIA-232-E, EIA-422-B
Data Format: ASCII
Compatibility EIA-232-E, EIA-422-B, PC Parallel, Dataproducts, IEEE 1284,
Twinax, Coax, Ethernet
Transfer
Rates
Up to 200K bytes/sec on parallel interfaces
Up to 19.2 K baud on RS-232 serial interface
Up to 115.2K baud on RS-422 serial interface
Buffer 16 kilobytes on serial interfaces
16 kilobytes on parallel interfaces
