Figure 6. Configuration Main Menu (con’t)
Parallel
Interface
5
page 136
Interface Type
PC Parallel
Dataproducts
IEEE 1284
Parallel Hotport
Emulation
Configuration
page 152
IPDS
3
Active Graphic Emulation
ANSI
6
IGP Emulation
3
Code V Emulation
3
ASCII Printer
Emulation
Printer Emul Config
Print Format
Operator
Print Tests
page 210
Printer Demonstration*
Print Error Log
Print Ribbon Log
Ripple Print
All E’s
All H’s
All E’s + FF
Underlines
Adapter Test Page
4
Ethernet Test Page
4
Clear Error Log
Printer
Information
page 212
Installed Memory
Power On Time
Printing Time
Print Strokes
11 Inch Pages
Serial
Interface
page 146
Interface Type
Data Protocol
Baud Rate
Data Bits
Stop Bits
Parity
Data Terminal Ready
Request To Send
Buffer Size In Kbytes
Poll Character
One Char Enquiry
Serial Hotport
Framing Errors
NOTE:
1
The Twinax and Coax interface menus only appear in the menus if the Coax/Twinax
feature is installed.
2
The Early Print Complete option appears in the Twinax menu only if the IPDS feature is
installed.
3
IPDS, Code V Emulation, and IGP Emulation options appear in the menus only if these
features are installed.
4
Ethernet information only appears when the ethernet feature is installed.
5
Ether the Ethernet Interface menu or the Parallel Interface menu will display. They
cannot display at the same time.
6
If installed.
7
Not if 4234-12 is running IPDS code.
8
Only if Autoswitching is enabled.
9
Only if Coax Emulation is enabled.
10
The 5250 and 3270 Interface menu only appear in the menus if the TN5250/3270
feature is installed.
11
Only if ANSI is selected.
