- 14 -
Item Description
RUN Command source Allows different methods of switching between command
sources:
● Operating panel (keypad & display)
● Terminal I/O control
● Serial communication
Main frequency reference
setting channel
Supports up to 10 frequency reference setting channels
and allows different methods of switching between
frequency reference setting channels:
● Digital setting
● Analog voltage reference
● Analog current reference
● Pulse reference
● Communication reference
Auxiliary frequency
reference setting channel
Supports up to 10 auxiliary frequency sources, and allows
ne tuning of the auxiliary frequency and main & auxiliary
calculation.
Input terminals Standard:
● Five digital input (DI) terminals, one of which supports
up to 100 kHz high-speed pulse inputs.
● Two analog input (AI) terminals, one of which supports
only 0 to10 V input, and the other supports 0 to 10 V
and 4 to 20 mA current input.
Expanded capacity:
● Five digital input (DI) terminals.
● One AI terminal that supports –10 to 10 V voltage input
and PT100/PT1000 motor temperature sensor inputs.
Output terminals Standard
● Single high-speed pulse output terminal (open-
collector) for a square-wave signal output in the
frequency range 0 to 100 kHz
● Single digital output (DO) terminal
● Single relay output terminal
● Single analog output (AO) terminal that supports either
a current output in the range 0 to 20 mA or a voltage
output in the range 0 to 10 V.
Expanded capacity:
● Single extra DO terminal
● Single extra relay output terminal
● Single extra AO terminal that supports either a current
output in the range 0 to 20 mA or a voltage output in
the range 0 to 10 V.
