6. Description of Parameters
- 191 -
6
6.10.5 Control of Digital Output (DO, Relay, FMR)
If a digital output terminal is set for function 20: Communication setting, you can control digital
output by using host computer.
The communication address and command of digital outputs are dened in the following table.
Related communication address and command are as follows:
Communication Address Command Description
2001H Bit0: DO1 output
Bit1: DO2 output
Bit2: Relay1 output
Bit3: Relay2 output
Bit4: FMR output
Bit5: VDO1
Bit6: VDO2
Bit7: VDO3
Bit8: VDO4
Bit9: VDO5
6.10.6 Control of Analog and High-speed Pulse Output (AO, FMR)
When F5-06, F5-07 or F5-08 = 12, you can control analog and high-speed pulse output by
using host computer.
The communication address and command of analog and high-speed pulse outputs are dened
in the following table.
Related communication address and command are as follows:
Communication Address Command Description
AO1 2002H 0 to 7FFF indicates 0% to 100%.
AO2 2003H
FMP 2004H
6.10.7 Parameter Initialization
You can initialize parameters via host computer by using this function. If FP-00 (user password)
is set to a non-zero value, verify password on host computer.
Once password passes verification, host computer performs parameter initialization within
30s. The communication address of password verication is 1F00H. Directly write correct user
password to this address to complete verication.
The communication address and parameter initialization command are dened in the following
table.
Communication Address Command Description
1F01H 1: Restore factory parameters
2: Clear the records
4: Restore the user backup parameters
501: Back up the current user parameters
