6. Description of Parameters
- 153 -
6
Function Code Parameter Name Display Range
U0-44
DI set for function state display 2 -
U0-44: It displays whether DI terminals set for functions 41 to 59 are active. The display format is
similar to U0-43. The 7-segment LEDs display functions 41–48, 49–56 and 57–59, respectively
from right to left.
Function Code Parameter Name Display Range
U0-58
Phase Z counting 0 to 65535
U0-58: It displays phase Z counting of current ABZ or UVW encoder. The value increases or
decreases by 1 every time encoder rotates one revolution forwardly or reversely. You can check
whether installation of encoder is normal by viewing U0-58.
Function Code Parameter Name Display Range
U0-59
Frequency Reference -100.00% to 100.00%
U0-60
Running frequency -100.00% to 100.00%
Function Code Parameter Name Display Range
U0-61
AC drive state 0 to 65535
U0-61: It displays the drive state. The data format is listed in the following table:
Bit0 0: Stop
1: Forward
2: Reverse
Bit1
Bi2 0: Constant
1: Accelerate
2: Decelerate
Bit3
Bit4 0: Bus voltage normal
1: Undervoltage
Function Code Parameter Name Display Range
U0-62
Current fault code 0 to 99
U0-63
Sending value of point-point
communication
-100.00% to 100.00%
U0-64
Number of slaves 0 to 63
U0-65
Torque upper limit -200.00% to 200.00%
U0-74
AC drive output torque -200.0% to 200.00%
U0-76
Low bits of accumulative power
consumption
0.0 to 999.0 (min. unit: 0.1°)
U0-77
High bits of accumulative power
consumption
0 to 65535 (min. unit: 1°)
U0-78
Linear speed 0 to 65535
