Inovance MD500 Series - Extension Cards

8. Peripherals and Options
- 230 -
8
The following table lists the extension cards that are available for use with the drive.
Name Model Function Frequency Dividing
Coefcient
Remark
I/O extension
card 1
MD38IO1 Provides the following:
● Five extra DI terminals.
● An analog input.
● A relay output.
● A digital output.
● An analog output.
Supports Modbus-RTU and CANlink
- Available for
all models
I/O extension
card 2
MD38IO2 Provides three extra DI terminals. - Available for
all models.
User
programmable
card
MD38PC1 User-programmable extension card,
completely compatible with the
Inovance H1U series PLC.
- Available for
all models.
CANlink
communication
card
MD38CAN1 Supports CANlink - Available for
all models.
CANopen
communication
card
MD38CAN2 Supports CANopen - Available for
all models.
Modbus
communication
card
MD38TX1 Supports Modbus-RTU Available for
all models.
Probus-DP
communication
card
MD38DP2 Supports PROFIBUS-DP Available for
all models.
Resolver interface
card
MD38PG4 For use with a resolver that has an
excitation frequency of 10 kHz. The
card has a DB9 interface.
Without frequency
dividing function
Available for
all models.
Open-collector
encoder interface
card
MD38PG5D Open-collector encoder interface card
with optional multiplying frequency
division output.
Requires a 15 VDC power supply.
2 to 62 even
frequency dividing
Available for
all models.
Differential
encoder interface
card
MD38PG6 Requires a 5 VDC power supply.
The card has a DB9 interface.
1:1 frequency
dividing
Available for
all models.
Differential
encoder interface
card
MD38PG6D With optional multiplying frequency
division output.
Requires a 5 VDC power supply.
The card has a DB9 interface.
2 to 62 even
frequency dividing
Available for
all models.
Multifunctional
encoder card
MD38PGMD Compatible of differential input, open-
collector input, push-pull input
Supports differential output and open-
collector output
0 to 63 frequency
dividing
Available for
all models.
