2. Mechanical Installation
- 26 -
Through hole installation of a sheet metal housing
■
Through-hole Mounting Bracket Models
Through-hole Mounting Bracket Model Applicable AC Drive Model Bracket Dimensions
MD500-AZJ-A1T5 MD500T18.5GB-INT
Refer to
8
.
5
T
h
r
o
u
g
h
-
h
o
l
e
M
o
u
n
t
i
n
g
B
r
a
c
k
e
t
.
MD500T22GB-INT
MD500-AZJ-A1T6 MD500T30GB-INT
MD500T37GB-INT
MD500-AZJ-A1T7 MD500T45GB-INT
MD500T55GB-INT
MD500-AZJ-A1T8 MD500T75GB-INT
MD500T90G-INT
MD500T110G-INT
MD500-AZJ-A1T9 MD500T132G-INT
MD500T160G-INT
