CUSA® Clarity System Service and Maintenance Manual Page 84 of 117 0645403-2-EN
• Unscrew and remove the 4 x SCREW, SHEET METAL, 6.3 X 16 MM Ref. S72905371 and the 2 x WASHER, M6 Ref. S72905393 as shown in
the Figure 9-20.
Figure 9-20
• Take out the Cart Weight Cover Ref. S72905051 as shown in Figure 9-21.
Figure 9-21
Installation
Refit the Cart Weigh Cover Ref. S72905051 as shown in Figure 9-22.
Unscrew
