CUSA® Clarity System Service and Maintenance Manual Page 85 of 117 0645403-2-EN
Figure 9-22
Refit the 4 x SCREW, SHEET METAL, 6.3X16 MM Ref. S72905371 and the 2 x WASHER, M6 Ref. S72905393 as shown in the Figure 9-23. Place MAX LOAD
LABEL Ref. S72905370 on the Cart Weigh Cover as shown in Figure 9-22.
Figure 9-23
Screw
