Integra DRX-8.4 User Manual

108
Playback
Playing Back (ZONE 2)
Note
• The audio from externally connected AV components can be output to ZONE
2 only when the audio is analog or 2 ch PCM signal. When the AV component
is connected to this unit with an HDMI cable, digital coaxial cable or digital
optical cable, change the audio output of the AV component to the PCM
output.
• When video and audio via HDMI input are output to ZONE 2, set "Input/
Output Assign" - "TV Out / OSD" - "Zone 2 HDMI" ( →p130) to "Use" on the
Setup menu.
• You can only select the same source for the main room and separate room
with the "NET" and "BLUETOOTH" input selectors. Furthermore, if you have
"NET" selected in the main room and you then select "BLUETOOTH" in the
separate room, the main room will also switch to "BLUETOOTH".
• It is not possible to select di󰀨erent stations in the main room and separate
room with AM/FM broadcasts. (North American and Taiwanese models)
• DSD audio signals cannot be output to ZONE 2 with the "NET" input selector.
• If ZONE 2 is on, power consumption during standby will increase.
• This function turns o󰀨 if you use "Transmitting audio from this unit to
BLUETOOTH wireless technology enabled devices" ( →p86).
Turning Zone 2 On/O󰀨
1. Face the remote controller at the unit, and while pressing and holding the
Zone 2 Hold button, press " ".
To control on the main unit, press the Zone 2 button on the main unit. When
turning o󰀨, within 8 seconds of pressing the Zone 2 button, press the O󰀨
button.
2
1
"Z2" lights in the main unit display when Zone 2 turns on. To turn Zone 2 o󰀨,
repeat the same procedure.
• When the power of this unit is switched to standby while using Zone 2, the
Z2 indicator lights dimly, and the mode switches to play only in the separate
room. Furthermore, the mode switches to play only in the separate room
when this unit is in standby mode and ZONE 2 is turned on.

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
