210
Appendix
General Specications
Amplier Section North American and Taiwanese models European, Australian and Asian models
Rated Output Power
(North American models)
With 8 ohm loads, both channels driven, from 20 Hz-
20 kHz; rated 150 watts per channel minimum RMS
power, with no more than 0.08% total harmonic
distortion from 250 milliwatts to rated output. (FTC)
(Taiwanese models)
11 ch × 220 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD (IEC)
11 ch × 220 W at 6 ohms, 1 kHz, 1 ch driven of 1% THD
(IEC)
Maximum E󰀨ective Output Power
(North American models)
260 W at 6 ohms, 1 kHz, 1 ch driven of 10% THD
11 ch × 260 W at 6 ohms, 1 kHz, 1 ch driven of 10%
THD (JEITA)
THD+N (Total Harmonic Distortion + Noise) 0.08% (20 Hz - 20,000 Hz, Rated output power)
Input Sensitivity and Impedance 200 mV/47 kΩ (LINE(RCA)), 3.5 mV/47 kΩ (PHONO MM) ± 0.2 mV/44 kΩ (LINE(XLR))
Rated RCA Output Level and Impedance
PRE OUT : 1 V/470 Ω
PRE OUT (ZONE 2) : 1 V/2.2 kΩ
LINE OUT (ZONE 2, ZONE B): 200 mV/2.2 kΩ
LINE OUT (ZONE 3) : 200 mV/470 Ω
Rated XLR Output Level and Impedance PRE OUT : 2 V/220 Ω
Phono Maximum Input Signal Voltage 70 mV (MM 1 kHz 0.5%)
Frequency Response 10 Hz - 100 kHz/+1 dB, –3 dB (Direct)
Tone Control Characteristics
MAIN : ±10 dB, 20 Hz (Bass), ±10 dB, 20 kHz (Treble)
ZONE 2 : ±10 dB, 100 Hz (Bass), ±10 dB, 10 kHz (Treble)
ZONE 3 : ±10 dB, 100 Hz (Bass), ±10 dB, 10 kHz (Treble)
Signal to Noise Ratio 107 dB (IHF-A, LINE IN, SP OUT), 78 dB (IHF-A, PHONO IN, SP OUT)
Supported impedance of Speakers 4 Ω - 16 Ω
Headphone Rated Output 75 mW + 75 mW (32 Ω, 1 kHz, 10% THD)
Supported impedance of Headphones 8 Ω - 600 Ω
Headphones Frequency Response 10 Hz - 100 kHz
