Integra DRX-8.4 User Manual

112
Playback
WHOLE HOUSE MODE
When the Whole House Mode button of the main unit is pressed during playback
in the main room, "Z2" and "Z3" on the display light up at the same time, and
the WHOLE HOUSE MODE function is turned on with which the same source is
played back at once in all rooms.
• Sources that can be played in ZONE 2 can be played in all rooms.
• In the following cases, this function cannot be used.
– When headphones are connected
– When audio is output from the speakers of the TV
– When "Speaker" - "Conguration" - "Zone 2 Preout" on the Setup menu is
set to "Zone B" ( →p136)
• Depending on the setting of "Speaker" - "Conguration" ( →p134) in the
Setup menu, it may not be able to output to ZONE 3.

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
