Integra DRX-8.4 User Manual

134
SetupSetup
2. Speaker2. Speaker
 1. Conguration
Change the settings of connection environment of the speakers.
• If the settings for "Speaker Channels", "Subwoofer", "Height 1 Speaker", or
"Height 2 Speaker" have been changed, the Dirac Live ( →p170, p174)
measurement results are deleted.
 Speaker Channels (Default Value: 7.1.4 ch)
Select "2.1 ch", "3.1 ch", "4.1 ch", "5.1 ch", "6.1 ch", "7.1 ch", "2.1.2 ch",
"3.1.2 ch", "4.1.2 ch", "5.1.2 ch", "6.1.2 ch", "7.1.2 ch", "4.1.4 ch", "5.1.4 ch",
"6.1.4 ch" or "7.1.4 ch" to suit the number of speaker channels connected.
 Subwoofer Preout (Default Value: SW 1 & SW 2)
Set whether a powered subwoofer is connected or not.
No When a powered subwoofer is not connected
SW 1 When connecting 1 or 2 powered subwoofers to the SW1
terminal
SW 1 & SW 2 When connecting 1 or 2 powered subwoofers to the SW1
terminal and SW 2 terminal
• Di󰀨erent signals are output from the SW1 and SW2 terminals. The volume
level can also be set separately. ( →p139)
The same signals are output from "A" and "B" of the SW1 terminal. The SW2
terminal also has the same specication.
 Passive Subwoofer (Default Value: No)
Set whether a passive subwoofer is connected or not.
No When a passive subwoofer is not connected
1 ch When 1 passive subwoofer is connected
• Connect to the HEIGHT 2 (SW1) jack.
2 ch When 2 passive subwoofers are connected
• Connect the rst to the HEIGHT 2 (SW 1) jack and the
second to the HEIGHT 2 (SW 2) jack.
• This setting cannot be selected under the following conditions.
– "Bi-Amp" is set to "Front/Center"
– "Zone Speaker" is set to "Zone 2/Zone 3"
– "Speaker Channels" is set to "6.1.4 ch" or "7.1.4 ch"
– "Speaker Channels" is set to "6.1.2 ch", "7.1.2 ch", "4.1.4 ch", or "5.1.4 ch" and
"Zone Speaker" is set to "Zone 2" or "Bi-Amp" is set to "Front"
– "Speaker Channels" is set to "2.1.2 ch", "3.1.2 ch", "4.1.2 ch", or "5.1.2 ch" and
"Bi-Amp" is set to "Front"
– "Speaker Channels" is set to "6.1 ch" or "7.1 ch" and "Zone Speaker" is set to
"Zone 2" and "Bi-Amp" is set to "Front"

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
