Integra DRX-8.4 User Manual

91
Playback
You can quickly set convenient features such as adjusting sound quality.
Quick Menu
HDMI
Audio
Room EQ
Level
Discrete Audio Path Mode
HDMI Out
A/V Sync
Audio Return Channel
BD/DVD
You can make the settings on the TV screen during playback. Press Q on the
remote controller to display the Quick Menu.
Select the item with the cursors / of the remote controller, and press the
Enter button to conrm your selection.
Use the cursors to change the settings.
• To return to the previous screen, press .
• To exit the settings, press Q.
Note
• When the input signals are ones that need a high bandwidth, such as 8K
signals, the Quick Menu may not be displayed.
 HDMI
Discrete Audio Path Mode: You can make the HDMI IN 1 jack exclusively for
audio to improve sound quality. Not that when this is set to on, the output of
video signals will stop and there will be no display on the TV screen.
• The display will appear on the TV screen when you press , but the video
signal out is stopped again when you press again.
HDMI Out: Select the HDMI OUT jack to output video signals from "MAIN",
"SUB", and "MAIN+SUB".
A/V Sync: If the video is behind the audio, you can delay the audio to o󰀨set the
gap. The setting can be set for each input.
• It cannot be set if the listening mode is Direct.
Audio Return Channel: You can enjoy the sound of the HDMI-connected ARC-
compatible TV through the speakers connected to the unit. Select "On" when
listening to the audio of TV using the speakers of this unit. Select "O󰀨" when the
ARC function is not used.
Quick Menu

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
