Integra DRX-8.4 User Manual

123
Playback
Connecting a transmitter for playback
When you connect wireless headphones or a wireless speaker transmitter to the ZONE B LINE OUT jacks of this unit, you can play back the same source through the
wireless headphones or wireless speakers as in the main room.
Connections
1. Use an analog audio cable to connect the ZONE B LINE OUT jacks on this
unit to the input terminal on the transmitter.
Transmitter
Setting Up
1. Press on the remote controller, and set "Speaker" - "Conguration" - "Zone
2 Preout" to "Zone B". ( →p136)
Playing Back
1. Press the Q button on the remote controller and select "Audio" - "Zone B".
• In the following cases, "Zone B" cannot be selected.
– When ZONE 2 is On
– When "Speaker" - "Conguration" - "Zone 2 Preout" on the Setup menu
is set to "Zone 2". ( →p136)
2. Select the audio output destination.
O󰀨: Outputs audio only from ZONE A. "A" on the display of the main unit
lights up.
On (A+B): Outputs audio from both ZONE A and ZONE B. "A" and "B" on the
display of the main unit light up.
On (B): Outputs audio only from ZONE B. "B" on the display of the main unit
lights up.
3. Start play on the AV component.
4. Adjust the volume on the transmitter, etc., in ZONE B.
• When "Zone 2 Preout" is set to "Zone B", and "Audio" - "Zone B" on the Quick
Menu is set to "On (A+B)", the ZONE A output is set as below.
– When the sound quality is adjusted with the Tone button, the sound quality
changes in both ZONE A and ZONE B.
– There will be no e󰀨ect for the surround back speakers from "Speaker" -
"Distance" ( →p138) in the Setup menu.
a
a Analog audio cable

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
