Integra DRX-8.4 User Manual

138
SetupSetup
2. Speaker
Double Bass:
This can only be selected when the setting for "Conguration" - "Subwoofer
Preout" is "SW 1" or "SW 1 & SW 2", or the setting for "Passive Subwoofer" is
"1ch" or "2ch", and the "Front" setting is "Full Band".
Boost bass output by feeding bass sounds from the front left and right
speakers and the center speaker to the subwoofer.
"On": Bass output is boosted.
"O󰀨": Bass output is not boosted.
• This function is not automatically set even if AccuEQ Room Calibration or
Dirac Live is performed.
 3. Distance
Set the distance from each speaker to the listening position.
 Front Left (Default Value: 12.0 ft/3.60 m)
Center (Default Value: 12.0 ft/3.60 m)
Front Right (Default Value: 12.0 ft/3.60 m)
Height 1 Left (Default Value: 9.0 ft/2.70 m)
Height 1 Right (Default Value: 9.0 ft/2.70 m)
Height 2 Left (Default Value: 9.0 ft/2.70 m)
Height 2 Right (Default Value: 9.0 ft/2.70 m)
Surround Right (Default Value: 7.0 ft/2.10 m)
Surr Back Right (Default Value: 7.0 ft/2.10 m)
Surr Back Left (Default Value: 7.0 ft/2.10 m)
Surround Left (Default Value: 7.0 ft/2.10 m)
Subwoofer 1 (Default Value: 12.0 ft/3.60 m)
Subwoofer 2 (Default Value: 12.0 ft/3.60 m)
• Default values vary depending on the regions.
• The unit of distance can be changed by pressing the Mode button on the
remote controller. When the unit is set as feet, you can set between 0' 0" 1/2
and 30' 0" in increments of 1/2. When using the unit "meter", the setting is
available in increments of 0.01 m from 0.01 m to 9.00 m.
• When measurements are made using Dirac Live ( →p170, p174), units are
displayed as "msec" and the value cannot be changed.
(Height 1 Left, Height 1 Right, Height 2 Left, Height 2 Right, Surr Back Right,
Surr Back Left):
• Depending on the use of the ZONE speakers, it may not be possible to select
this setting.

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
