Integra DRX-8.4 User Manual

11
Part Names
Front Panel (North American and Taiwanese models)
A On/Standby button
B Hybrid Standby indicator: Lights up when
any of the following functions is working or
enabled in standby state of this unit. When this
indicator is lighting, the power consumption in
standby state increases, however, the increase
in power consumption is minimized by entering
the HYBRID STANDBY mode where only the
essential circuits operate.
– HDMI CEC ( →p149)
– HDMI Standby Through ( →p149)
– USB Power Out at Standby ( →p156)
– Network Standby ( →p157)
– Bluetooth Wakeup ( →p157)
C HDMI Out button: Select the HDMI OUT jack to
output video signals. ( →p129)
D Remote control sensor: Receives signals from
the remote controller.
• The reception range of the remote controller
is within a distance of approx. 16´/5 m, and
an angle of 20° in vertical direction and 30° to
right and left.
E Tone button: You can adjust the sound quality of
the speakers. Press the Tone button to select an
item to adjust from "Bass", "Vocal" and "Treble",
and press + and - to adjust.
F Listening Mode button: Switches the listening
mode ( →p83, p195) by pressing "Movie/
TV", "Music" and "Game" button repeatedly.
G Display ( →p15)
H Dimmer button: Switches the brightness of the
display with three levels. It cannot be turned o󰀨
completely.
I Memory button: Used to register AM/FM radio
stations. ( →p90)
J Tuning Mode button: Used to switch between
automatic tuning and manual tuning for AM/FM
stations. ( →p88)
European, Australian and Asian models ( →p13)
A B
C
D
E F
G
H IJ

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
