84
Playback
BLUETOOTH
®
Playback
You can wirelessly play music on a smartphone or other BLUETOOTH wireless technology enabled device through the speakers connected to this unit. It is also
possible to transmit the audio from this unit to BLUETOOTH enabled headphones, wireless speakers, etc.
Playing audio from BLUETOOTH wireless technology enabled devices with this unit
Perform the following procedure when this unit is on.
Pairing
1. When you press the Bluetooth button, "Now Pairing..." appears on the display,
and the pairing mode is enabled.
2. Enable (turn on) the BLUETOOTH function of the BLUETOOTH enabled
device, and then select this unit from among the devices displayed. If a
password is requested, enter "0000".
This unit is displayed as "Integra DRX-8.4 XXXXXX". This display can be
changed using the Friendly Name function ( p152) or Integra Control
Pro ( p173) (available on iOS or Android™).
To connect another BLUETOOTH enabled device, press and hold the
button at least 5 seconds, and then perform step 2. This unit can store the
pairing information of up to 8 paired devices.
The coverage area is approx. 48´/15 m. Note that connection is not always
guaranteed with all BLUETOOTH enabled devices.
If pairing fails, then in the Setup menu, set "Hardware" - "Bluetooth" -
"Bluetooth Transmitter" ( p155) to "O󰀨" and "Bluetooth Receiver"
( p154) to "On".
Integra DRX
-
XXX
The illustration shows an image.

Table of Contents

Other manuals for Integra DRX-8.4

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Integra DRX-8.4 and is the answer not in the manual?

Integra DRX-8.4 Specifications

General IconGeneral
Channels11.2
Amplification TypeClass AB
THD+N0.08%
HDMI Inputs7
HDMI 2.1Yes
HDR SupportHDR10, Dolby Vision, HLG
eARCYes
Phono InputYes
Zone 2/3 Powered OutputsYes
USB Input1 (Front)
EthernetYes
Wi-FiYes
BluetoothYes
Standby Power Consumption0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)250 W/Ch
Input Sensitivity and Impedance200 mV/47 kOhms (Line)
Signal-to-Noise Ratio106dB
Speaker Impedance4 Ohms – 16 Ohms
HDMI Outputs3
Digital Audio InputsOptical: 2, Coaxial: 1
Pre-Outs11.2 Ch
Speaker Terminals11
Streaming ServicesAirPlay 2, Spotify, Tidal, Deezer
Voice ControlAmazon Alexa, Google Assistant
Room CorrectionAccuEQ
Supported Audio FormatsDolby Atmos, DTS:X
Weight14.5 kg (32 lbs.)
