Integra DRX-8.4 User Manual

143
SetupSetup
3. Audio Adjust3. Audio Adjust
 1. Multiplex/Mono
Change the settings of multiplex audio playback.
 Multiplex Input Channel (Default Value: Main)
Set the audio channel or language to be output when playing multiplex audio or
multilingual broadcasts, etc.
• For multiplex audio broadcasts, pressing the
button on the remote
controller will display "1+1" on the main unit’s display.
Main Main channel only
Sub Sub channel only
Main / Sub Main and sub channels will be output at the same time.
 Mono Input Channel (Default Value: Left + Right)
Set the input channel when playing back analog or 2 ch PCM signals in the
Mono listening mode.
Left Left channel only
Right Right channel only
Left + Right Left and right channels
 Mono Output Speaker (Default Value: Center)
Set the speaker to output monaural audio in the Mono listening mode.
• If an item cannot be selected even though connection is correct, check that
the settings in "Speaker" - "Conguration" - "Speaker Channels" matches the
number of connected channels.
Center Audio is output from the center speaker.
Left / Right Audio is output from the front L/R speakers.
 2. Dolby
Change the setting of when Dolby signals are input.
 Loudness Management (Default Value: On)
When playing Dolby TrueHD, enable the dialog normalization function which
keeps the volume of dialog at a certain level. Note that when this setting is O󰀨,
the Late Night function that allows you to enjoy surround at low volumes is xed
to o󰀨 when playing Dolby Digital Plus/Dolby TrueHD.
On When this function is used
O󰀨 When this function is not used
 Center Spread (Default Value: O󰀨)
Adjust the width of the front sound eld created when playing back with the
Dolby Audio - Surr listening mode.
• Depending on the speaker settings, "O󰀨" is applied.
On The sound eld is spread to left and right.
O󰀨 The sound eld is centralized.

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
