Integra DRX-8.4 User Manual

162
SetupSetup
7. Multi Zone7. Multi Zone
 1. Zone 2
Change the settings for Zone 2.
 Output Level (Default Value: Fixed)
Select whether to adjust the volume on the integrated amplier in the separate
room or on this unit when outputting to the separate room (Zone 2).
Fixed Adjust on the integrated amplier in the separate room
Variable Adjust on this unit
 Maximum Volume (Default Value: O󰀨)
Set the maximum value for Zone 2 to avoid too high volume. Select a value
from "O󰀨", "50" to "99". (When "Audio Adjust" - "Volume" - "Volume Display" is
set to "Absolute")
 Power On Volume (Default Value: Last)
Set the Zone 2 volume level of when this unit is turned on. Select a value from
"Last" (Volume level when the unit was turned o󰀨), "Min", "0.5" to "99.5" and
"Max". (When "Audio Adjust" - "Volume" - "Volume Display" is set to "Absolute")
• You cannot set a higher value than that of "Maximum Volume".
 Sound Check (Default Value: -)
Output test tones to ZONE 2 to enjoy audio in a separate room (ZONE 2) in
addition to the main room.
Press Enter while "Start" is being displayed. Operate by following the on-
screen displays.
 2. Zone 3
Change the settings for Zone 3.
 Output Level (Default Value: Fixed)
Select whether to adjust the volume on the integrated amplier in the separate
room or on this unit when outputting to the separate room (Zone 3).
Fixed Adjust on the integrated amplier in the separate room
Variable Adjust on this unit
 Maximum Volume (Default Value: O󰀨)
Set the maximum value for Zone 3 to avoid too high volume. Select a value
from "O󰀨", "50" to "99". (When "Audio Adjust" - "Volume" - "Volume Display" is
set to "Absolute")
 Power On Volume (Default Value: Last)
Set the Zone 3 volume level of when this unit is turned on. Select a value from
"Last" (Volume level when the unit was turned o󰀨), "Min", "0.5" to "99.5" and
"Max". (When "Audio Adjust" - "Volume" - "Volume Display" is set to "Absolute")
• You cannot set a higher value than that of "Maximum Volume".
 Sound Check (Default Value: -)
Output test tones to ZONE 3 to enjoy audio in a separate room (ZONE 3) in
addition to the main room.
Press Enter while "Start" is being displayed. Operate by following the on-
screen displays.

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
