Integra DRX-8.4 User Manual

163
SetupSetup
7. Multi Zone
 3. Remote Play Zone
Change the settings for remote play.
 Remote Play Zone (Default Value: Auto)
When playing with AirPlay or Spotify Connect, or when using the Music Server
function to play remotely from your PC, you can set whether to play in the main
room (where this unit is located) or in a separate room (ZONE 2/ZONE 3).
Auto When the main room input is NET, music is played in the main
room. When the separate room input is NET and the main
room input is other than NET, then the music is played in the
separate room.
Main,
Zone 2,
Zone 3
Select when limiting the play zone to a particular room. For
example, when playing only in the separate room, select "Zone
2" or "Zone 3".
• This function may not work if playback is already proceeding with the same
network function.

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
