Integra DRX-8.4 User Manual

152
SetupSetup
6. Hardware
 Friendly Name (Default Value: Integra DRX-8.4 XXXXXX)
Change the model name of this unit which is displayed on the device
connected to the network to an easily recognized name.
1. Press Enter to display the Edit screen.
2. Select a character or symbol with the cursors, and press Enter.
Repeat this operation to input up to 31 characters.
"A/a": Switches between upper and lower cases. (Pressing Mode on the
remote controller also toggles between upper and lower cases)
"←" "→": Moves the cursor in the arrow direction.
" ": Removes a character on the left of the cursor.
" ": Enters a space.
• Pressing Clear on the remote controller will remove all the input
characters.
3. After inputting, select "OK" with the cursors, and press Enter.
The input name will be saved.
 AirPlay (Default Value: On)
Select whether or not to use the AirPlay function.
On When this function is used
O󰀨 When this function is not used
 AirPlay Device Name (Default Value: Integra DRX-8.4 XXXXXX)
Change the model name of this unit which is displayed on the AirPlay-
connected device to an easily recognized name.
1. Press Enter to display the Edit screen.
2. Select a character or symbol with the cursors, and press Enter.
Repeat this operation to input up to 31 characters.
"A/a": Switches between upper and lower cases. (Pressing Mode on the
remote controller also toggles between upper and lower cases)
"←" "→": Moves the cursor in the arrow direction.
" ": Removes a character on the left of the cursor.
" ": Enters a space.
• Pressing Clear on the remote controller will remove all the input
characters.
3. After inputting, select "OK" with the cursors, and press Enter.
The input name will be saved.
• This function cannot be used when registering this unit to Home App.

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
