Integra DRX-8.4 User Manual

153
SetupSetup
6. Hardware
 AirPlay Password (Default Value: -)
You can set a password of up to 31 characters so that only users that have
input can use AirPlay.
1. Press Enter to display the Edit screen.
2. Select a character or symbol with the cursors, and press Enter.
Repeat this operation to input up to 31 characters.
"A/a": Switches between upper and lower cases. (Pressing Mode on the
remote controller also toggles between upper and lower cases)
"←" "→": Moves the cursor in the arrow direction.
" ": Removes a character on the left of the cursor.
" ": Enters a space.
• To select whether to mask the password with "" or display it in plain text,
press Memory on the remote controller.
• Pressing Clear on the remote controller will remove all the input
characters.
3. After inputting, select "OK" with the cursors, and press Enter.
The input password will be saved.
• This function cannot be used when registering this unit to Home App.
 Privacy Statement (Default Value: Not Accepted)
When using a network service that requires a login name, email address,
password, etc., you need to agree to the Privacy Statement of our company.
• This setting can be made after conrming the Privacy Statement. When
you select "Privacy Statement" and press Enter, the Privacy Statement is
displayed.
• When "Not Accepted" is selected, the login name, email address, password,
etc., that are kept on this unit will be deleted and you will be logged out from
the network service you have logged in.
 Network Check (Default Value: -)
You can check the network connection.
Press Enter when "Start" is displayed.
• Wait for a while if "Network" cannot be selected. It can be selected when the
network function is activated.

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
