Integra DRX-8.4 User Manual

139
SetupSetup
2. Speaker
 4. Level Calibration
Adjust the volume level of each speaker.
 Front Left (Default Value: 0.0 dB)
Center (Default Value: 0.0 dB)
Front Right (Default Value: 0.0 dB)
Height 1 Left (Default Value: 0.0 dB)
Height 1 Right (Default Value: 0.0 dB)
Height 2 Left (Default Value: 0.0 dB)
Height 2 Right (Default Value: 0.0 dB)
Surround Right (Default Value: 0.0 dB)
Surr Back Right (Default Value: 0.0 dB)
Surr Back Left (Default Value: 0.0 dB)
Surround Left (Default Value: 0.0 dB)
Subwoofer 1 (Default Value: 0.0 dB)
Subwoofer 2 (Default Value: 0.0 dB)
Select a value between "-12.0 dB" and "+12.0 dB" ("-15.0 dB" and "+12.0 dB"
for Subwoofer) (in 0.5 dB increments). A test tone will be output each time you
change the value. Select the desired level.
(Height 1 Left, Height 1 Right, Height 2 Left, Height 2 Right, Surr Back Right,
Surr Back Left):
• Depending on the use of the ZONE speakers, it may not be possible to select
this setting.
 5. Dolby Enabled Speaker
Change the settings of Dolby Enabled Speakers.
• This setting can be selected when "Conguration" - "Height 1 Speaker" /
"Height 2 Speaker" is set to "Dolby Speaker".
 Distance from the ceiling (Default Value: 6.0"/1.80 m)
Set the distance between the Dolby Enabled Speaker and the ceiling. Select
between "0' 0" 1/2"/"0.01 m" and "15' 0"/"4.50 m" ("1/2 ft"/"0.01 m" units).
• The unit of distance (ft/m) is displayed using the unit selected for the
"Distance" setting.
 AccuReex (Default Value: O󰀨)
You can enhance the reection e󰀨ect of Dolby Enabled Speakers from the
ceiling.
• The function is not e󰀨ective if the listening mode is Direct.
• The function is not e󰀨ective if "Dirac Live" ( →p93) has been enabled.
O󰀨 When this function is not used
On When this function is used

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
