Integra DRX-8.4 User Manual

140
SetupSetup
2. Speaker
 6. Equalizer Settings
You can adjust the output volume of the range for each connected speaker.
Adjust the volume of di󰀨erent sound ranges for each speaker. You can set
three di󰀨erent equalizers in Preset 1 to 3. The number of frequencies that can
be selected for each speaker is up to ve bands for the Subwoofer and fteen
bands for the other speakers.
 Preset 1
Preset 2
Preset 3
Check
Select the Preset to be set with the cursors / , then press the Enter
button.
When you select "Check", you can check what the settings are for each input
selector.
Front (Default Value: 0.0dB)
Center (Default Value: 0.0dB)
Height 1 (Default Value: 0.0dB)
Height 2 (Default Value: 0.0dB)
Surround (Default Value: 0.0dB)
Surround Back (Default Value: 0.0dB)
Subwoofer (Default Value: 0.0dB)
Select the speaker to be set with the cursors / , then press the Enter
button. Next, after selecting the speaker frequency from between "25 Hz" and
"16 kHz" ("25 Hz" and "160 Hz" for Subwoofer) with the cursors / , adjust
the volume of that frequency between "-6.0 dB" and "+6.0 dB" with / .
• Depending on the input source or listening mode setting, the desired e󰀨ect
may not be achieved.
(Height 1 Left, Height 1 Right, Height 2 Left, Height 2 Right, Surround Back):
• Depending on the use of the ZONE speakers, it may not be possible to select
this setting.
(Subwoofer):
• This cannot be selected if "Conguration" - "Subwoofer Preout" or "Passive
Subwoofer" is set to "No".

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
