Integra DRX-8.4 User Manual

136
SetupSetup
2. Speaker
 Zone 2 Preout (Default Value: Zone 2)
Set an output destination of the audio output from ZONE 2 PRE/LINE OUT/
ZONE B LINE OUT jack.
• This setting is xed to "Zone 2" when "Zone Speaker" is set to "Zone 2" or
"Zone 2/Zone 3".
Zone 2 When connecting an integrated amplier in a separate room
(ZONE 2)
Zone B When connecting an integrated amplier, transmitter of
wireless headphones, etc. to ZONE B
 Bi-Amp (Default Value: No)
Set whether the speakers are bi-amp connected.
• You cannot select a setting other than "No" or "Front" when using ZONE
speakers.
No When no speakers are bi-amp connected
Front When only front speakers are bi-amp connected
• This setting cannot be selected under the following
conditions.
– "Speaker Channels" is set to "6.1.4 ch" or "7.1.4 ch"
– "Speaker Channels" is set to "6.1.2 ch", "7.1.2 ch", "4.1.4
ch", or "5.1.4 ch" and "Zone Speaker" is set to "Zone 2" or
"Zone 2/Zone 3"
– "Speaker Channels" is set to "6.1 ch", "7.1 ch", or "2.1.2 ch"
to "5.1.2 ch" and "Zone Speaker" is set to "Zone 2/Zone 3"
Front/Center When front speakers and the center speaker are bi-amp
connected
This can only be selected when you have set "Speaker
Channels" to "3.1 ch", "5.1 ch", or "7.1 ch".
 Speaker Impedance (Default Value: 6 ohms or above)
Set the impedance (Ω) of the connected speakers.
• For impedance, check the indications on the back of the speakers or their
instruction manual.
4ohms When any of the connected speakers have 4 Ω or more to less
than 6 Ω impedance
6 ohms or above When all the connected speakers have an impedance of 6 Ω
or more

Integra DRX-8.4 Specifications

General

Channels	11.2
Amplification Type	Class AB
THD+N	0.08%
HDMI Inputs	7
HDMI 2.1	Yes
HDR Support	HDR10, Dolby Vision, HLG
eARC	Yes
Phono Input	Yes
Zone 2/3 Powered Outputs	Yes
USB Input	1 (Front)
Ethernet	Yes
Wi-Fi	Yes
Bluetooth	Yes
Standby Power Consumption	0.15 W
Power Output (8 Ohms, 20 Hz-20 kHz, 0.08% THD, 2 Channels Driven, FTC)	140W
Power Output (6 Ohms, 1 kHz, 10% THD, 1 Channel Driven)	250 W/Ch
Input Sensitivity and Impedance	200 mV/47 kOhms (Line)
Signal-to-Noise Ratio	106dB
Speaker Impedance	4 Ohms – 16 Ohms
HDMI Outputs	3
Digital Audio Inputs	Optical: 2, Coaxial: 1
Pre-Outs	11.2 Ch
Speaker Terminals	11
Streaming Services	AirPlay 2, Spotify, Tidal, Deezer
Voice Control	Amazon Alexa, Google Assistant
Room Correction	AccuEQ
Supported Audio Formats	Dolby Atmos, DTS:X
Weight	14.5 kg (32 lbs.)
